CMYK four color printing signature strip card with 13.56mhz chip

Each rfid ISO card is well packed with a clear plastic foil.
Printable, Credit Card Size. Hotel door cards

contact now

product details

CMYK four color printing signature strip card with 13.56mhz chip

FM11RF08 (F08) is according to ISO14443 Type A developed by Shanghai FuDan Microelectronics Co., Ltd.

This chipset has 1K × 8bits EEPROM organization.

The maximum communication rage between the reader and contactless card is approximately 10cm.

Specifications:

SPECIFICATIONS RFID ISO CARD
Material:	PVC
Dimension:	85.6x54x0.88
Surface:	Glossy, matt, frosted laminated
Color:	white,no printing
Frequency:	13.56MHz
Chip:	MIFARE Classic EV1 1K

Chip Features:

1 Kbyte, organized in 16 sectors with 4 blocks of 16 bytes each (one block consists of 16 byte)

User definable access conditions for each memory block

Mutual three pass authentication (ISO/IEC DIS 9798-2)

Individual set of two keys per sector (per application) to support multi-application with key hierarchy

4Bytes Unique serial number

Contactless transmission of data and supply energy (no battery needed)

Operating distance: Up to 100mm (depending on antenna geometry)

Operating frequency: 13.56 MHz

Data transfer: 106 kbit/s

Data integrity: 16 Bit CRC, parity, bit coding, bit counting

Anticollision

Typical ticketing transaction: < 100 ms (including backup management)

Applications:

Payment

Access Control

Time Attendance

Hotel Key Card

Public transportation

Access control

Event ticketing

Gaming & identity

Available crafts:

Magnetic strip:

1_ Low-coercivity (loco) at 300 OE

2_ High-coercivity (hico) at 2750 OE

Signature panel and scratch panel

Barcode in different types(39/EAN 13/EAN 128...)

Hot stamping gold/silver color

Personalization:

Numbers or texts in thermal/inkjet /embossed/laser engraved/UV printing , Offset printing CMYK full color printing, Silk printing Panton Color value, digital printing, thermal printing, laser printing and ink-jet printing.

- Offset CYMK 4 colours

This is the most common method used in commercial printing.

The CMYK refers to the four inks used in the printing process: Cyan, Magenta, Yellow and Key (Black)

- Screen Printing

This method is used when the artworks only have limited colours and the accuracy is important

We accept custom material and artwork/design order

If you are interests of our Blank Plastic PVC Card,RFID ISO CARD Contact us today! Custom is accepted! Best prices.

hot tags : 13.56 MHz RFID ISO Cards Contactless ISO Cards signature strip card PVC signature strip card colorful signature strip card Signature Strip Cards
